Standard Pump
The Ebara CNPA Pump is a horizontal split case pump designed for high-volume water transfer with reliable and energy-efficient performance. Its compact horizontal design allows easy installation and simple maintenance, making the Ebara CNPA Pump an excellent choice for commercial buildings, municipal water systems, and industrial applications.
Built to deliver stable flow, high capacity, and long-term durability, the Pompa Ebara CNPA is engineered to support fire protection systems, water distribution networks, and other critical operations where reliability is a must.
Compact horizontal design for easy installation and maintenance.
Split case structure allows quick access to internal components.
Available in both electric motor and diesel engine configurations.
High efficiency with reduced vibration and low noise operation.
Wide capacity range up to 1250 USGPM.
Operating pressure up to 250 psi with ANSI 250 lb flanges.
Fully complies with NFPA 20 standards and is UL listed.
Liquid handled: Clean water (0–80°C)
Max. working pressure: 250 psi
Approval: UL listed
Capacity: Up to 1250 USGPM
Total head: Up to 120 m
Rotation: Clockwise (CW) viewed from driver end
Range: Electric motor or diesel engine
Material: Cast iron casing, bronze impeller (standard)
Coupling: Flexible coupling
Flanges: ANSI 250 lb
